Seaside Modular Announcements Thread: v2.5.2

Hi everyone,

Just wanted to let you know about Proteus, a new generative sequencer in the Library. The philosophy behind Proteus (the shapeshifting sea-god), is to allow you to generate melodies and explore the boundaries between repetition and change.

What Proteus does is to generate a melody, then repeat that melody until it gets bored, at which point it will create a brand new melody. How does it decide when it gets bored? There is an internal cumulative probability distribution, so Proteus is pretty much guaranteed to repeat your melody a few times, but as it approaches the number of repetitions set by lambda (controllable by knob or CV) the probability of a new melody will rapidly increase.

Proteus’s melodies are not just random notes: it chooses carefully from a scale with weighted probabilities, and it favors repeating notes and adjacent notes, so that its melodies are more musical than random notes.

Control the density of notes, the length of the sequence, the scale, the probability of octave transpositions and note mutations with the knobs or with CV, and lock in a melody if you really like it using the switches.


Video demo:


Congrats and thanks for the cool module!

If I can sneak in a small suggestion/request: would it be possible to make it such that when we have locked it to a sequence we like, the sequence gets saved/reloaded when we close/reopen the patch?


Cool, I’m playing with it. Is it always in the key of C?

In there a way to do a reset on the module so it can by synced with other modules?

Yes that’s a great idea, thanks!


Very nice! I appreciate that you provided a lengthy and informative video to explain the module. That’s a huge plus to quickly get up to speed. I’m looking forward to taking Proteus for a spin.


Saw the Youtube movie , at one point I started shouting “Lock Cursor While Dragging”, it prevents the constant moving of the screen :wink:

Module looks very useful.


Most, but not all sequencers in VCV Rack include a RESET input so multiple sequencers can sync.

1 Like

“Lock Cursor While Dragging”

Oh man, thank you so much. lol


looks great! Eager to try it out! Thanks so much for building this thing!

1 Like

I really like it. I have it accompanying my Meander module which is generating a harmonic progression in C major with a bassline and Proteus playing an evolving scale sequence with mutations. Works pretty well, even though I have not found a way to sync it to Meander other that to a common clock.

Good job, both on the hardware and the VCV module.

1 Like

Looks cool. I’m eager to mess with it! I wonder about quantization. Should “none” be an option? There’s a ton of other scales, like the presets in the VCV quantizers. I don’t know how tied your algorithm is to the 12 tone scale.

1 Like

We can add scales that have microtones (and I do intend to, I have a background in North Indian Classical music), so it’s not tied to a 12 tone scale really – but I think it does need to have some quantization to function.

1 Like

Then chromatic would be good to add, at a minimum.


i’m not sure if i’m doing something wrong, or what, but once i connect a clock to the clock input, the gate output goes high and stays high, outputting a constant 10V. is this expected?

EDIT: i tried adjusting the gate length parameter but it didn’t make any difference.

No, it shouldn’t do that. There may be a bug in calculating the time between triggers if it is left idle for a while (working on this one). But try disconnecting the cables and then re-connecting them.

no such luck, unfortunately. once a clock input is connected, the gate goes high and stays that way until i delete the module and add a new one. :confused:

EDIT: nevermind, it’s suddenly working now. i have no idea what was wrong before, but it’s working as expected now.

1 Like

I’m not following what you are saying here. Are the non-pentatonic scales non-heptatonic? Or are you saying that you can add some non-heptatonic scales and non-chromatic scales?

I quite often send the Meander “poly external scale” output to the Grande Quant quantizer so I can quantize anything to whatever mode and root Meander is set to, Meander has a menu option to output either in 12 channel (chromatic) heptatonic or pentatonic scales. Meander can also output the current scale in 7 channel heptatonic or 5 channel pentatonic scale. Proteus always sounds good when the notes are sent through a Grande Quant that is set to the Meander chromatic heptatonic or pentatonic scale. I would think that other quantizers could be used without Meander in the mix.

This is your topic and I certainly do not want to hijack it. I get excited when I find a module that is similar to my Meander module, I always like to explore the other modules and see what I can learn in the process, If you also like doing so, you might want to take a look at Meander.

Whereas you use “a Poisson cumulative density function”, Meander uses “fractal Brownian motion” (fBm) with specific values for persistence and lacunarity making it “1/f” time correlated noise

Meander has a long 34 year history with the original for Windows around 1992 having a lot more things similar to your Proteus. That Meander had a “mini sequencer” that allowed semi-fixed sequences to be defined, as well as a drum machine. It also had about 39 scales but I removed all but the mode scales for VCV Rack as Meander for Rack is harmony driven and it is next to impossible to form nice chords from many scales. Even with much of the original functionality removed, Meander for Rack is made up of about 12,000 lines of code. But it actually is not a CPU hog since it is a sequencer and does very little DSP per sample calculations.

But, that old Windows version still works fine and I launch if fairly often to look at how I did things way back when.

I look forward to see what all I can do with Proteus.

Wonderful module, really liking it already, thank you! And nice, low CPU usage too.

Here are some suggestions that would make it even more musically useful to me:

  • Octave range: 4 octaves of total range is often too wild, at least for the music I make :slight_smile: Would love an option in the context menu to switch between 2, 3 or 4 octaves of range, as produced by the OCTAVE mutation knob and DIR switch.

  • Octave mutation: As it is now the whole sequence is transposed x octaves up/down. I would love an option in the context menu to tie it to note-mutation, so that the octave mutation would only occur on the one note that is mutated, having the effect of “throwing in” an octave transposed note here and there.

  • DIR switch: Since this concerns the octave transposition, might I suggest instead calling it something like “OCT DIR” and the tooltips on it something like “Down”, “Up/Down” and “Up”.

  • Scale: Would be lovely to have more scales to choose from, so maybe either a “Chromatic” or “None” option, and then I can have another quantizer after the module with my chosen scale, or alternatively throw in all the scales from the VCV quantizer module, and make them selectable on right-click on the Scale knob, or something like that.

  • Density: As it is now the density is locked to new melody generation. It would be lovely if it was freely usable always, also in the freeze modes, if possible. That would increase its utility drastically.

  • Lock CV: It would be really nice to have the lock mode exposed for control via CV. There’s just one space left to the right of clock :slight_smile:

Very enjoyable module though, thanks!
